74LX1G05

ObsoleteLogic Gates / Flip-Flops输入电压 0 ~ 5.5 V封装 SOT23

Single inverter open drain

Manufacturer: STMicroelectronics
Package: SOT23
Datasheet: 10 pages · 141 KB
Website: www.st.com

Wrong information or a copyright issue? Let us know

74LX1G05 Key Specifications

Source: manufacturer datasheet

输入电压	0 ~ 5.5 V
封装	SOT23

Technical Documents

1 document

Datasheet

Single inverter open drain
10 pages141 KBST-74LX1G05.pdf

Alternatives

0 parts

No alternatives listed for 74LX1G05 yet.
